Hobbywing Quicrun Wp 1060 60a 2~3s Brushed Esc 1/10 1/12 Rc Car

For More Great Items Visit our eBay Store here-----> https://www.ebay.com/str/totsrc
QUICRUN 1060 Series 60 Amp Brushed ESC
For 1/10 1/12 Car

Specification

Hobbywing QuicRun WP 1060 60A Brushed ESC
FEATURES
• Water-proof and dust-proof, suitable for all-weather condition races.
• Small size with built-in capacitor module.
• QUICRUN-WP-1060-BRUSHED ESC with 3 running modes Fwd / Rev / Br Forward/Brake Forward/Reverse (crawler mode)
• Great current endurance capability.
• Great built-in BEC output capacity. 6volts 3 amps
• Automatic throttle range calibration, easy to use.
• Easy to set the ESC parameters with jumpers.
• Multiple protections: Low voltage cut-off protection for battery / Over-heat protection / Throttle signal loss protection.
Specifications:
Fwd. Cont. / Peak Current :60A/360A
Rev. Cont. / Peak Current:30A/180A
Voltage Range:2-3S Lipo or 5-9 NiMH
Cars Applicable:1/10 1/12: Touring Car, Buggy, Monster, Truggy, Rock Crawler and Tank
Motor Limit:
540 or 550 Size Motor: >12T or RPM<30000 @7.2V
540 or 550 Size Motor: >18T or RPM<20000 @7.2V
Resistance:Fwd 0.001Ω, Rev 0.002Ω
BEC Output:3A / 6V Switch Mode
Dimension / Weight:36x32x18mm / 39g
Cooling Fan:Without cooling fan
Running Mode: F-R-B / F-B / F-R

Package List
1 * 1060 60A ESC
1 * Adhesive Label Paper
1 * Cable Binding Tape
1 * Manual (English)
1 * Original Box
